Click for Details. Air Cavity Pre-Molded Open Caviy QFN ready for die and wire bonding

M-QFN Series

Open Tooled Packages
8L 3x3mm • 12L 3x3mm
16L 3x3mm • 16L 4x4mm
20L 4x4mm • 24L 4x4mm
32L 5x5mm • 40L 5x5mm
40L 6x6mm • 48L 6x6mm
48L 7x7mm • 56L 8x8mm
64L 9x9mm • 72L 10x10mm
80L 12x12mm

Open Cavity (air cavity) QFN package:
•MEMS, RF, sensor, and silicon applications.
•Ready for die attach and wire bonding.
•For engineering and rapid prototypes.
•Complies to JEDEC Standard MO-220 VQFN

Lids Flat and dome covers.

Sockets Window for probing into cavity.

Engineering Kit Packages and lids for evalution.

CAD DXF and PDF drawings center.
